Description
Features
● Patent Male-female linkable design
● Seamless & No Dark in-line connection
● UL ETL DLC TUV SAA approved
● 0.8mm aluminum housing for excellent heat dissipation
● Heat protection system with excellent internal driver
● Easy replacement and installation with brackets
Applications
● Replaces fluorescent NCF fittings,
● Warehouses, factories & food storage,gymnasium
● Car parks & sports facilities, Kitchens,shopping malls
Technical Specifications
● Input Voltage: AC100-277V / AC100-240V 50/60Hz
● Total harmonic distortion: THD<19%
● Power Factor: PF>0.95
● Efficiency: 120-140LM/W
● Color Index: Ra>82
● IP Rating: IP40
● Life Span: 50,000 hours
● Lumen maintenance @6000h: >80%
● Switching Time: 100,000
● Operation Temperature: -20°C ~ +50°
Options
-Fuctions: Normal / Triac Dimmable / ON-OFF Switch
-Connection Way: Lead in wire / M-F Connection / Power cord with Plug
-Installation Type : Standard Clip / Magnetic Clip / Suspending Kits
Additional information
| COLOR | 3000k, 4000k, 6000k |
|---|---|
| SIZE | 9", 11", 23", 34", 46 ", 58" |
